Mini Led controller SP110E Addressable LED Bluetooth Dimmer Controller DC 5-12V 1024 Pixels for SK6812 WS2812 Programmable RGB LED Magic Color Strip
About this item
【Bluetooth Remote Control.】IOS and Android App remote control via Bluetooth ; IOS 10.0 or Android 4.4 or later edition required. 20m Long distance remote control; convenient to use. Your smart Phone should support Bluetooth 4.0 or later version.
【Wide Compatibility】 Support almost all the LED driver ICs, such as WS2811,WS2812B, SK6812, SK6812-RGBW. But there is no WS2812B option on the setting page, please choose WS2811 when connect it to WS2812B LEDs.
【Rich color modes】Come with 120 kinds of dynamaic color change modes, tons of static color, which are vivid and beautiful. Color hue, brightness and speed are adjustable. When you connect SK6812-RGBW LED Strip, the white channel can be adjusted individually.
【User-friendly design】Support setting IC types, R/G/B sequence and pixels number, control up to 1024 pixels in total. Save user setting when power off. DC 5V~12V wide working voltage; reverse connection protection; hot swap protection.
【Warnings】The controller can’t regulate the output voltage at the VCC. That means the output voltage of your power supply must be the same as the work voltage of your led lights. If your lights need 5V input, please use a 5V power supply, never use 12V power supply. Otherwise, your lighes will be damaged.
Basic parameters:
1. Model: SP110E Symphony Bluetooth Controller
2.APP program: LED Hue
3. Input voltage: DC5-12V
4. Working current: 20mA~40mA
5. Product size: 50*20*10mm
8. Weight: about 30g
9. Connection method: DC interface is connected to power supply, 3pin terminal interface is connected to light strip
10. Control distance: about 30 meters
11. Certification: CE, ROHS
12. Can control 1024 pixels.
The package includes:
SP110E Controller * 1
