Features:
1. APP controlled via WiFi, compatible with multiple Art-Net computer software ;
2. BluFi configuration using dual mode chip(WIFI&BT);
3. Support AP mode and STA mode;
4. Two layout setting method: regular rectangle layout setting and importing DXF files ;
5. Support two layers overlay, built-in multiple types of effect layers: text layer, music effect layer…;
6. The effect layers support a variety of custom parameters: direction, width, color, length, shape…;
7. Real-time preview, support recording the current scene to the controller storage;
8. Support change device name ,reorder the RGB order, and OTA update.
Specifications:
Working temperature : -20℃~60℃;
Working Voltage : DC5V~24V;
Working Current : 25mA~130mA;
Flash Capacity : 128M;
Output signal: 4-port TTL signals;
Maximum pixel number : 1024 / port;
LED driver IC: Normal one-wire RZ code LED driver IC.
